Wagner Radiator Kit, Audi B9 RS4, RS5 F5

Competition – Radiator – Kit for Audi RS4 B9 / RS5 F5

This kit is designed for a seamless plug-and-play installation in the following models:

• Audi RS4 B9 331KW/450PS from 2017
• Audi RS5 F5 331KW/450PS from 2017

The Audi RS4 and RS5 are powered by a robust 2.9L V6 biturbo engine, which features an indirect charge-air cooling system. Unlike traditional setups that use ambient air for cooling, this system utilizes its own cooling water circuit. Lowering the temperature of the cooling water directly enhances the cooling performance of the charged air, and that’s where the WAGNERTUNING upgrade water cooler shines.

The newly developed competition racing core of the WAGNERTUNING high-performance water coolers boosts the radiator volume of the OEM units by an impressive 55%. The design optimizes the ratio between the inner and outer cooling surfaces, maximizing heat transfer while ensuring sufficient airflow for surrounding components, like the engine water cooler, to perform their own heat exchange. Plus, these coolers come with a heat-conductive anti-corrosion coating to maintain a long-lasting cooling effect. Installation is straightforward, and an instruction manual is included to guide you through the process.

Dimensions of OEM radiator:

• 720 mm x 485 mm x 25 mm
• Volume: 8.73 Liters
• Area: 3492 cm²

Dimensions of WT radiator:

• 690 mm x 490 mm x 40 mm
• Volume: 13.52 Liters
• Area: 3381 cm²

Key Features:

• Increased radiator volume by 55%
• Optimized heat transfer design
• Heat-conductive anti-corrosion coating
• Plug-and-play installation

Applications:

• Audi RS4 B9 331KW/450PS from 2017
• Audi RS5 F5 331KW/450PS from 2017
